Zooming Into a CPU (It's Incredible)
Branch Education
Jul 9, 2026 17:18
Create an account to hide videos, mark them watched, or save them to Don't Miss.
Create an account to hide videos, mark them watched, or save them to Don't Miss.
Create an account to hide videos, mark them watched, or save them to Don't Miss.
When you zoom into a CPU, SoC, or any microchip in general, you'll find a nanoscopic sea of transistors, each just a few nanometers wide, grouped into logic gates called standard cells. To wire a full processor together, it takes 18 stacked layers upon layers of intricate wiring with the transistors at the bottom and then progressively larger wires up top — all connected vertically by vias.
Watch the full video to see how it all fits together. 🔬https://youtu.be/_Pqfjer8-O4
#semiconductors #chips #engineering #howitworks #technology #smartphone #transistors #computerscience
