DIY Ultrasonic Audio Laser (Directional Speaker)
Mean Gene Hacks
Apr 28, 2020 05:51
Create an account to hide videos, mark them watched, or save them to Don't Miss.
Create an account to hide videos, mark them watched, or save them to Don't Miss.
Create an account to hide videos, mark them watched, or save them to Don't Miss.
Chapters
Build your own ultrasonic audio laser, otherwise known as an ultrasonic parametric speaker that lets you beam sound to distant places like a laser beam. Total cost is under $20!
Parts List:
-----------------
(17) TCT-16T 40Khz Ultrasonic Transducers TCT40-16T - https://www.aliexpress.com/item/32258563531.html
(1) STM32F103C8T6https://www.aliexpress.com/item/32862385518.html
(1) LM358 (DIP-8) - https://www.aliexpress.com/item/32972282817.html
(1) TC4427A - https://www.aliexpress.com/item/32967076106.html
(1) PJ-307 Line-in Audio Jack - https://www.aliexpress.com/item/1000006982803.html
(1) MT3608 DC Step-Up Module (optional) - -https://www.aliexpress.com/item/4000155588081.html
Code and schematics:
------------------------------------
https://github.com/gururise/directional_speaker
#parametricspeaker #ultrasound #audiolaser
